SG-AE3

适合材质:

Projection ratio	inch	W/mm	H/mm	L.R	Up	Down	Electric long	Chief Electrician	W/mm	H/mm	≈KG	Total height after unfolding
SG-AE1 Electric Platinum Aluminum Series Dimensional Table Unit: mm
Specifications		Projection size		Black part/mm			Non cable size length		Aluminum cover		weight	Total height after unfolding
16:9	80	1771	996	40	600	40	2041	1951	110	170	9-11	1831
16:9	92	2037	1146	40	600	40	2307	2217	110	170	10-11	1981
16:9	100	2214	1245	40	500	40	2484	2394	110	170	12-13	1980
16:9	106	2347	1320	40	500	40	2617	2527	110	170	12-14	2055
16:9	120	2657	1494	40	300	40	2927	2837	110	170	13-15	2029
16:9	133	2945	1656	50	300	50	3235	3145	110	170	15-17	2201
16:9	150	3321	1868	50	300	50	3611	3521	110	170	17-20	2413
16:10	80	1724	1078	40	550	40	1994	1904	110	170	10-11	1863
16:10	92	1983	1239	40	550	40	2253	2163	110	170	10-11	2024
16:10	100	2155	1347	40	500	40	2425	2335	110	170	12-13	2082
16:10	106	2284	1428	40	500	40	2554	2464	110	170	12-14	2163
16:10	120	2586	1616	40	300	40	2856	2766	110	170	13-15	2151
16:10	133	2866	1791	50	300	50	3156	3066	110	170	15-17	2336
16:10	150	3233	2020	50	300	50	3523	3433	110	170	17-20	2565
4:3	72	1463	1097	40	40	40	1733	1643	110	170	8-9	1372
4:3	84	1707	1280	40	40	40	1977	1887	110	170	9-11	1555
4:3	100	2032	1524	40	40	40	2302	2212	110	170	12-13	1799
4:3	120	2438	1829	40	40	40	2708	2618	110	170	15-17	2104
4:3	150	3048	2286	50	40	50	3338	3248	110	170	17-19	2571
